MST-50 - C600 - V15 - perpendicular engine Customised industrial actuators
Industrial actuator - Assembly with reducer with screw and fixation by back screed
Accueil | Electric Actuators | Customised industrial actuators |
MST-50 - C600 - V15 - perpendicular engine
MST-50 - C600 - V15 - perpendicular engine
MST-50 - C600 - V15 - perpendicular engine
Industrial actuator - Assembly with reducer with screw and fixation by back screed
High-end special actuators of high capacity, the MSK50 offer up to 6 tons of force and 2.5 m of race. Thanks to their quiet operation and their environmentally friendly system, they are a reliable and powerful solution in many areas. Some applications: - High speed process - Long stroke applications - Strength joining process - Special machines
Customised industrial actuators
- Product range
- Industrial actuator - Mounting with screw reducer and rear clevis mounting
- Wiper
- Scraper doubles at the exit of the stalk
- Color treatment
- Acrylic paint RAL 9007
- Brake
- Yes
- Screw type
- Trapezoid screw TR60x9
- Length of stroke
- 600
- Temperature range
- -25 to 80
- Stem material
- Chrome-plated hard
- Stem
- With anti-rotation system
- Limit switch
- With information of return
- Stem mounting
- Tip with kneecap zinc-plated or zinc-plated screed
- Body attachment
- Anti-corrosion treated screed
- Body material
- Steel
- Product range
- Industrial actuator - Assembly with reducer with screw and fixation by back screed
- Displacement force (max. force)
- 50000
- Stroke speed
- 15
- Limit switch
- SME-8
- Number of poles
- 4
- Operating factor
- S1
- Type of voltage
- Three-phase
- Supply voltage
- 400
- IP protection type
- IP 54
- Brake voltage
- 400
- Motor power
- 4
- Options
- Electric Limiteur of mechanical overload. Sensor of position: coder or linear potentiometer Tachometer Threading of various steps Execution for outdoor use and in corrosive environment.
- Accessories
- Landings supports Screed of fixationNut of safety Bellows and tubes of protection
