BINDER premium 75 AT20 GEN III

Synchroflex® standard belt

Power belts
Grayed out functions require you to be logged in to your account
login to my account
Tangential force transmissible by the teeth
Range
BINDERpremium
Product range power belts
Synchroflex® standard belt
Applications
Precision application
Profile / Pitch
AT20
Profile
AT
Pitch
20
PU Material steel tension member
DNHU 9333
Shore hardness steel tension member belt
93 ShA
Temperature range of steel tension member belt
-20 à 100 °C
Winding
wire
P max
≤250 kW
Steel tension member permissible force FN
21600 N
N max
6500 tr/min
V max
40 m/s
Standard belt lengths
1000, 1200, 1600, 1760, 1260, 1960, 1500, 1800, 1100, 1700, 1900 mm
Belt width
75 mm
Weight
0,87 kg/m
Number of teeth
80, 90, 85, 55, 60, 75, 95, 98, 50, 88, 63
Z min single bending standard cable
18
Ø min Flexion simple câble standard
120 mm
Z min alternating bending standard cable
25
Ø min alternée simple câble standard
180 mm
