ECH150-40- DC100% Solenoids
Solenoid for simple operation
Solenoid for simple operation
ECH150-40- DC100% : with its machined cylindrical design, this robust single-action electromagnet delivers high forces. In the vertical position, take into account the weight of the core.
Solenoids
- Product range
- Solenoid for simple operation
- Body length
- 238
- Body length
- 238 mm
- Coil weight
- 4600
- Coil weight
- 4600 g
- Total weight
- 21000
- Total weight
- 21000 g
- Product range
- Solenoid for simple operation
- Function
- Pulling/pushing
- Diameter
- 150
- Diameter
- 150 mm
- Options
- Other voltages and duty factors on request.
- Stroke
- 40
- Stroke
- 40 mm
- Force at beginning of stroke
- 250
- Force at beginning of stroke
- 250 N
- Force at end of stroke
- 1100
- Force at end of stroke
- 1100 N
- Internal return spring
- no
- Duration of attraction
- 1272
- Duration of attraction
- 1272 ms
- Recoil time
- 781 ms
- Recoil time
- 781
- Duty cycle
- 100
- Duty cycle
- 100 %
- Duration of the cycle for the calculation
- 5
- Duration of the cycle for the calculation
- 5 min
- Power
- 120
- Power
- 120 W
- Connection
- IP65 connector
- Insulation class
- B
- Standard voltages
- 24
- Standard voltages
- 24 V
- IP protection
- IP40
