BINDER ACCESS 16 T10 BAS M

BINDER ACCESS 16 T10 BAS M


BRECObasic® belt

Linear belts
Download the 3D file
Download PDF
Grayed out functions require you to be logged in to your account
login to my account
Tangential force transmissible by the teeth
Range
BINDERaccess
Linear belt product range
BRECObasic® belt
Application
Simple application
Profile / Pitch
T10
Profile
T
PU Material steel tension member
Grey TPU BAS
Shore hardness steel tension member PU belt
92 ShA
Temperature range of steel tension member belt
0 to 80 °C
Winding
S+Z
Weight
0,073 kg/m
Width tolerance
+/- 0.5 mm
Pitch
10 mm
Belt width
16 mm
Length tolerance
+/-0.8 mm
Thickness tolerance of the tooth
0,1/-0,3 mm
Tolerance of thickness of the tooth
0/-0.1 mm
Z min single bending standard cable
12
Ø min Flexion simple câble standard
60 mm
Z min alternating bending standard cord
20
Ø min alternée simple câble standard
60 mm
Constant stiffness of the CSPE reinforcement (steel)
0,35*10^6 N
Steel tension member permissible force FN
1400 N
N max
10000 tr/min
V max
60 m/s
Product range
BRECObasic® belt
Options
PAZ
Additional information
Storage: 50 or 100 m rolls and longer lengths on request
