BINDERclassic 50TK10K13 basic M Linear belts
BRECObasic® belt
BRECObasic® belt
BINDERclassic 50TK10K13 basic M: this belt is intended for simple applications that do not require high positioning accuracy and that operate under limited tensile stresses. It is available in T10 and AT10 profiles.
Linear belts
- Range
- BINDERaccess
- Linear belt product range
- BRECObasic® belt
- Width tolerance
- +/- 0.5 mm
- Pitch
- 10 mm
- Belt width
- 50 mm
- Length tolerance
- +/-0.8 mm
- Thickness tolerance of the tooth
- 0,1/-0,3 mm
- Tolerance of thickness of the tooth
- 0/-0.1 mm
- Z min alternating bending stainless steel cord
- 40
- Ø min alternée simple câble Inox
- 130 mm
- Z min single bending standard cable
- 25
- Ø min Flexion simple câble standard
- 80 mm
- Z min alternating bending standard cord
- 25
- Ø min alternée simple câble standard
- 80 mm
- Application
- Self-guided precision application
- Profile / Pitch
- TK10
- Profile
- TK
- Double toothed belt
- no
- PU Material steel tension member
- Grey TPU BAS
- Shore hardness steel tension member PU belt
- 92 ShA
- Temperature range of steel tension member belt
- 0 to 80 °C
- Winding
- S+Z
- Weight
- 0,407 kg/m
- Guide profile
- K13F
- Product range
- BRECObasic® belt
- Options
- PAZ
- Additional information
- Storage: 50 or 100 m rolls and longer lengths on request
- Constant stiffness of the CSPE reinforcement (steel)
- 1,1*10^6 N
- Steel tension member permissible force FN
- 4200 N
- N max
- 10000 tr/min
- V max
- 60 m/s
