BINDERclassic 100TK10K13 basic M Linear belts
BRECObasic® belt
BRECObasic® belt
Linear belts
- Range
- BINDERaccess
- Linear belt product range
- BRECObasic® belt
- Application
- Self-guided precision application
- Profile / Pitch
- TK10
- Profile
- TK
- Double toothed belt
- no
- PU Material steel tension member
- Grey TPU BAS
- Shore hardness steel tension member PU belt
- 92 ShA
- Temperature range of steel tension member belt
- 0 to 80 °C
- Winding
- S+Z
- Weight
- 0,735 kg/m
- Guide profile
- K13F
- Width tolerance
- +/- 0.5 mm
- Pitch
- 10 mm
- Belt width
- 100 mm
- Length tolerance
- +/-0.8 mm
- Thickness tolerance of the tooth
- 0,1/-0,3 mm
- Tolerance of thickness of the tooth
- 0/-0.1 mm
- Z min alternating bending stainless steel cord
- 40
- Ø min alternée simple câble Inox
- 130 mm
- Z min single bending standard cable
- 25
- Ø min Flexion simple câble standard
- 80 mm
- Z min alternating bending standard cord
- 25
- Ø min alternée simple câble standard
- 80 mm
- Constant stiffness of the CSPE reinforcement (steel)
- 2,20*10^6 N
- Steel tension member permissible force FN
- 8400 N
- N max
- 10000 tr/min
- V max
- 60 m/s
- Product range
- BRECObasic® belt
- Options
- PAZ
- Additional information
- Storage: 50 or 100 m rolls and longer lengths on request
