M27/28-0

M27/28-0


Fixed rollers

The M Series Lightweight Fixed Roller is designed for front mounting. The bearings are greased for a long time to a special grease. Temperature resistance: 70 ° C permanently, 120 ° C in short point.
Rollers
Download PDF
Grayed out functions require you to be logged in to your account
login to my account
Product range
Fixed rollers
Type
M
Material
Al
Belt maximum width
25
Belt maximum width
25 mm
Dimension B
27
Dimension B
27 mm
Dimension D
28
Dimension D
28 mm
Dimension B2
39,5
Dimension B2
39,5 mm
Dimension D1
17,5
Dimension D1
17,5 mm
Dimension B1
26
Dimension B1
26 mm
Product range
Fixed rollers
Dynamic load
6200 N
Dynamic load
6200
Static load
3450
Static load
3450 N
Max. speed
15000
Max. speed
15000 tr/min
Profile / Pitch
Lisse
